Cadillac Big Brake Kit
>
BBK For Cadillac ATS CT4 CT5 CT6 CTS Big Brake Kit 6 Piston Caliper With 378*32mm Rotor

BBK For Cadillac ATS CT4 CT5 CT6 CTS Big Brake Kit 6 Piston Caliper With 378*32mm Rotor

Brand Name: TEI Racing
Model Number: S60
MOQ: 1
Packaging Details: 42*42*42cm Brand Box
Payment Terms: T/T, Western Union, MoneyGram,Paypal
Detail Information
Place of Origin:
China
Car Model:
Cadillac ATS CT4 CT5 CT6 CTS
Car Of Year:
2000-2021
Piston:
6pistons
Wheel Size:
18inch 19inch 20inch
Weight:
35kg For Full Kit
Material:
Aerial 6082 Aluminum Alloy
Color:
Black Red Yellow Green Blue Silver
Supply Ability:
200 kits per month
Highlight:

ATS CT4 Big Brake Kit

,

Cadillac CT5 Big Brake Kit

,

Aerial 6082 6 Piston Caliper

Product Description



BBK For Cadillac ATS CT4 CT5 CT6 CTS Big Brake Kit 6 Piston Caliper with 378*32mm rotor





The Cadillac CT4  BBK is a compact executive sedan marketed by Cadillac BBK since 2019. It replaced the Cadillac ATS BBK , and it was unveiled twice: the CT4-V on May 30, 2019, and the standard CT4 Big Brake kit four months later.[5] Cadillac will assemble the CT4 at the Lansing Grand River Assembly plant in Lansing, Michigan.

The CT4 will sit below the CT5 in Cadillac's  lineup. It will be available in early 2020 in the U.S



What's in the Box

Passenger Side Front TEI Racing Six-Piston Caliper

Driver Side Front TEI Racing Six-Piston Caliper

2-piece TEI Racing Front Rotors

Braided Stainless Steel Brake Lines

Brake Pads (one set, for both calipers)

Mounting Brackets

Installation Hardware











Brake Pads
Material: Ceramic Graphite
Heat Resistant:0-500C
Friction Coefficient:0.49

BBK For Cadillac ATS CT4 CT5 CT6 CTS Big Brake Kit 6 Piston Caliper With 378*32mm Rotor 0


Rotor (Disc+Center Hub)
craft: Forged
Plane Bounce:<0.03mm
Material:
1,Disc:High Carbon Iron
2,Center Hub: Aerial 6061 Aluminum Alloy


ROTOR SPECS:

2-piece floating rotors with 6061-T6 aerospace grade alloy hat.

Fully balanced from the factory
Rotor ring in FC30 cast iron with anti corrosion coating.
Drilled / slotted / drilled and slotted rotor ring available at no extra cost.


(We advise drilled for street and slotted only for track and race applications)
Curved vanes ventilation for optimal cooling.
Full-floating rotors use floating hardware with anti-rattle system (removable and rebuildable).
It provides a lower tendency to warp, less drag and wear as the rotor ring centers itself with the pads.
Available for 330mm rotors and bigger only.
The semi-floating rotor uses standard bolts instead and the rotor is fixed on the hat.
Custom rotor hat anodized color


Brackets/Adapters
Material: Aerial 6061 Aliminum Alloy
Craft: CNC

BBK For Cadillac ATS CT4 CT5 CT6 CTS Big Brake Kit 6 Piston Caliper With 378*32mm Rotor 1


Brake Hose/Brake line

Material: Inside teflon, Braided Stainless steel mid layer ,Protective outer PVC weather proof shell

Our brake kit is supplied with a Goodridge Style Brake line kit with stainless lines; consisting of a PTFE inner and stainless steel braided outer to eliminate the spongy feel of original rubber hoses, provide superior resistance to corrosion, and offer consistent braking performance.

BBK For Cadillac ATS CT4 CT5 CT6 CTS Big Brake Kit 6 Piston Caliper With 378*32mm Rotor 2



WARRANTY:

10 years on calipers casting, caliper parts, and seals.
2 years on mounting hardware and brackets.
Lifetime Warranty on brake lines. DOT approved
10,000km / 3 months on rotors.







The number of pots of the calipers will also play a role in term of pressure applied on the pads to make the contact as good as possible on the rotors. In order to fit the caliper on your original chassis, TEI Racing provides caliper brackets to position the calipers with your new braking system, making the perfect set up for your car brakes system.

Go fast and stop faster. TEI Racing Big Brake Kits provide you with serious braking power when you need it most. TEI Racing brake kits are offered for both the front and rear brakes with rotor sizes ranging from 285mm-405mm drilled or slotted or drilled and slotted, 2-6 piston Forged Monoblock aluminum caliper options, and custom colors. Stainless steel brake lines, brake pads, and all hardware are included for a direct bolt-on installation where no modifications are required.

TEI Racing Monoblock calipers are precision machined from aircraft quality billet aluminum and feature heavy duty aluminum pistons mated to temperature resistant seals. These high performance calipers are able to utilize a lightweight construction while providing dramatically increased braking performance. The rotors included in TEI Racing big brake kits features a two-piece design with drilled or slotted surfaces which help minimize fade and dissipate heat under the most extreme braking.

TEI Racing Rotor Size Minimum Inch Wheel Size
285*24mm 15inch wheels
300*24mm 16inch wheels or above
300*28mm 17inch wheels or above
330*28mm 17inch wheels or above
345*28mm 18inch wheels or above
355*32mm 18inch wheels or above
378*32mm 19inch wheels or above
405*34mm 20inch wheels or above





Installation Info

Installation Time

(approx) 4 Hours

Difficulty Level:

Mechanical expertise or professional installation required.
